STAUFF Push-to-Connect Couplings
Series HUS – G1″ BSPP Port Complete Coupling
Product Description
STAUFF push-to-connect HUS series couplings consist of a Female body and a Male tip and ensure the assembly of two connecting tube or hose ends can be quickly and easily coupled and uncoupled by hand, without the need of a tool.
Series HUS is made according to the Nordic interchange and available in nominal sizes: 10, 12, 19, 25 (3/8”- 1”)
Product Features
▪ Female and male parts are Zinc-Nickel plated
▪ Poppet valves available to prevent uncoupled leakage
▪ Male and female poppet valves fitted standard with decompression valve (pressure eliminator)
▪ Critical parts are hardened for durability
▪ Dependable ball-locking mechanism holds the mating halves together
▪ Female coupling is supplied standard with safety lock ring
▪ Working Pressure: 260 bar / 3770 PSI
Product Applications
▪ Heavy road transport equipment
▪ Construction machinery
▪ Forestry machinery
Item No:
QRC-10011 + QRC-10021 (MUST BE ORDERED AS A PAIR)
INTERCHANGE
TEMA – T Series
CEJN – 525 Series
Holmbury – F Series
DNP PTK1 Series
Valid until 31st July 2025 or until stock is sold
